AGV 22

AGV 22 - BIDIRECTIONAL WAFER KNIFE GATE VALVE

DESCRIPTION

  • Bidirectional wafer-design knife gate valve.
  • “Monoblock” onepiece cast iron body.
  • Stainless steel gate. Two rubber sleeves.
  • Provides high flow rates with low pressure drop.
  • Various seat materials available.
  • Face-to-face dimension in accordance with AAP Techniks standard.

GENERAL APLICATIONS

This knife gate valve is suitable for working in the mining industry, in loaded fluid transport lines, such as: water with stones, sludge, etc. and in general it is used for abrasive fluids in the chemical industry and waste water.


Designed for the following applications :

  • Thermal power stations
  • Energy Sector
  • Chemical plants
  • Mining
  • Sewage treatment

SIZES

DN50 a DN1500 (larger sizes on request).

WORKING PRESSURE (P)

  • DN 50-600 = 10 bar 10Kg/cm2
  • DN 700-900 = 4 bar 6Kg/cm2
  • DN 1000-1500 = 2 bar 4Kg/cm2

The pressures indicated in the table, can be used in either of the valve’s two directions. Other pressures on request.

FLANGE DRILL HOLE

DIN PN10 & ANSI B16.5 (150 LB)

OTHER COMMON FLANGES

  • DIN PN 6 Australian standard.
  • DIN PN 16 JIS standard.
  • DIN PN 25 British standard.

DIRECTIVES

Pressure Equipment Directive:

  • (PED) ART 4.3 /CAT.1.

De atmósferas explosivas:

  • Potential Explosive Atmospheres Directive

QUALITY DOSSIER

All valves are tested hydrostatically at AAP Techniks, and material and test certificates can be provided.

  • Body test = working pressure x 1,5
  • Seat test = working pressure x 1,1
