AGV 33
AGV 33 - BIDIRECTIONAL "LUG" KNIFE GATE VALVE
DESCRIPTION
- Bidirectional knife gate valve.
- Monoblock cast-iron body.
- Stainless steel knife gate. Polyurethane inner body liner.
- It provides high flow rates with low pressure losses.
- Face-to-face distance according to AAP Techniks standard does not require sealing joints between the flanges as they are incorporated in the body.
GENERAL APLICATIONS
This knife gate valve is suitable for working in the mining industry, in conveyance lines (e.g. loaded with water and stones, sludge, etc.), and generally for abrasive fluids with different concentrations of solids without discharge into the environment, such as the chemical and wastewater indus- tries.
Designed for the following applications :
- Mining industry
- Water treatment
- Electrical power stations
- Chemical plants
- Energy sector
- Thermal power stations
SIZES
DN50 to DN600 (larger sizes on request).
The pressures shown in the table can be used in either valve direction.
WORKING PRESSURE (∆P)
DN50 - DN600 = 10 bar
FLANGE DRILL
DIN PN10 & ANSI B16.5 (150 LB)
OTHER COMMON FLANGES
- DIN PN 6 Australian Standard.
- DIN PN 16 JIS Standard.
- DIN PN 25 British Standard.
QUALITY DOSSIER
All valves are tested hydrostatically at AAP Techniks, and material and test certificates can be provided.
- Body test = working pressure x 1,5
- Seat test = working pressure x 1,1
