AGV 26
AGV 26 - BIDIRECTIONAL WAFER KNIFE GATE VALVE
DESCRIPTION
- One-piece cast body.
- Provides high flow rates with low pressure drop.
- Various seat and packing materials available.
- Face-to-face dimension in accordance with AAP Techniks standard.
GENERAL APLICATIONS
This knife gate valve is suitable for liquids that contain a maximum of 4% suspended solids.
Designed for the following applications :
- Paper Industry
- Mining
- Chemical plants
- Pumping
- Food Industry
- Sewage treatment
In all these applications, the valve should be installed once the fluid has been filtered, to eliminate solids or large particles it contains.
SIZES
DN50 to DN600.
WORKING PRESSURE (∆P)
| DN50-DN200 | 10 bar |
|---|---|
| DN250-DN400 | 6 bar |
| DN450 | 5 bar |
| DN500 | 4 bar |
| DN600 | 3 bar |
The indicated working pressures are valid both ways.
STANDARD FLANGES
- ENI092 PN10.
- ASME B16.5 (clase 150).
OTHER COMMON FLANGES
- PN6.
- PN16.
- PN25.
- BS “D” and “E”.
- JIS10K.
QUALITY DOSSIER
All valves are tested hydrostatically at AAP Techniks, and material and test certificates can be provided.
- Body test = working pressure x 1,5
- Seat test = working pressure x 1,1
